COMPLETE PDF PARTS CATALOG MANUAL FOR AMMANN AFW700-2 SN JG002437 – STV5100G SN 3102503 | (PDF DOWNLOAD)
1. Discover the AMMANN AFW700-2 and STV5100G Parts Catalogue Manual, a comprehensive PDF resource designed for professionals seeking detailed information on these essential machinery models. This manual provides an extensive overview of parts, ensuring you have the right components at your fingertips for efficient maintenance and repairs.
2. With clear diagrams and part numbers, the catalogue simplifies the process of identifying and ordering the necessary parts, saving you time and reducing downtime. Whether you're a seasoned technician or a DIY enthusiast, this manual is an invaluable tool for keeping your equipment in top condition.
3. Invest in the AMMANN AFW700-2 and STV5100G Parts Catalogue Manual today to enhance your operational efficiency. Equip yourself with the knowledge to maintain your machinery effectively and ensure optimal performance for years to come.
MODEL COVERED :
AMMANN AFW700-2 SN JG002437 – STV5100G SN 3102503
CONTENT INCLUDED :
Service, repair and wear part kits, Stage IIIa / Tier3
Wear part and Inspection kits TIER 3 1
Auger kits
40-4812027478 Wear part kit auger wings Ø380mm 2
Hopper kits
40-4812018441 Wear part kit hopper rubber, standard 3
Conveyor kits
40-4812016662 Conveyor plates cpl. 4
40-4812035553 Wear part kit reversing roller 5
40-4812029821 Wear part kit conveyor chain 6
40-4812035552 Wear part kit conveyor drive 7
40-4812235936 Wear part kit conveyor guide plates 8
Service kits
Service kit 500 h
40-4812024673 Service kit 500 h TIER 3 9
Service kit 1000 h
40-4812024679 Service kit 1000 h TIER 3, stage 2 10
40-4812024680 Filter kit 1000h 12
Mechanical, Stage IIIa / Tier3
40-4812016133 Main frame
40-4812016133 Main frame 13
40-4812231640 Splash guard 14
40-4812036083 Steering guide 15
40-4812030969 Battery bracket 16
40-4812232117 Extension 17
40-4812027554A Side Screed arms, mech. locked
40-4812027554A Gr.06 Side Screed arms, mech. locked 18
40-4812029222 Locking, mechanical 20
40-4812029165 Side screed arm, l.h.
40-4812029165 Side screed arm, l.h. 21
Side bar guiding
40-4812232214 Side arm guiding 23
40-4720000097 Side arm guiding 24
40-4812029197 Side screed arm, r.h.
40-4812029197 Side screed arm, r.h. 25
Side bar guiding
40-4812232214 Side arm guiding See page 23
40-4720000097 Side arm guiding See page 24
40-4812046462A Push roller
40-4812046462A Gr.03 Push roller 28
40-4812046568 Pillow block 29
40-4812226472B Covering – from 0G001452, 1457, 1459 ff.
40-4812226472B Gr.12 Covering 30
40-4812226548 Bulk head 34
40-4812225685 Hood support 35
TOTAL PAGES - 499
FILE FORMAT: PDF
LANGUAGE: ENGLISH
EXCEPTIONAL SUPPORT 24X7, SECURE, EASY ORDERING
COMPATIBLE: ALL VERSIONS OF WINDOWS, ANDROID & MAC
DOWNLOAD: YOU WILL RECEIVE LINK ON YOUR EMAIL AFTER PURCHASE.
