COMPLETE PDF PARTS CATALOG MANUAL FOR AMMANN AFT600-3 SN AM3006405, STV5100E SN 3103815 | (PDF DOWNLOAD)

1. Discover the AMMANN AFT600-3 and STV5100E Parts Catalogue Manual, a comprehensive PDF resource designed for efficient maintenance and repair of your machinery. This manual provides detailed diagrams, part numbers, and specifications, ensuring you have all the information needed to keep your equipment running smoothly.

2. With the AMMANN AFT600-3 SN AM3006405 and STV5100E SN 3103815 included, this catalogue is tailored to meet the specific needs of your models. Whether you're a seasoned technician or a DIY enthusiast, the clear layout and organized sections make it easy to locate the parts you need quickly.

3. Invest in the AMMANN Parts Catalogue Manual today and enhance your operational efficiency. Having this essential guide at your fingertips will save you time and reduce downtime, allowing you to focus on what matters most—getting the job done right.

MODEL COVERED :
AMMANN AFT600-3 SN AM3006405, STV5100E SN 3103815

CONTENT INCLUDED :
Service, repair and wear part kits, Stage V
Wear part and Inspection kits Stage V 1
Auger kits
40-4812027478 Wear part kit auger wings Ø380mm 3
40-4812075191 Renewal kit I, auger drive – Valid from 0G001393, ff. 4
40-4812075192 Renewal kit II, auger drive 5
Hopper / pushroller kits
40-4812018438 Wear part kit hopper rubber, front hopper flap 6
40-4812018439 Wear part kit hopper rubber, standard 7
40-4812075204 Renewal kt, push roller 8
Conveyor kit
40-4812238491 Wear part kit conveyor guide plates 9
40-4812238624 Wear part kit conveyor guide plates, Hardox 400 10
40-4812238584 Wear part kit conveyor plates 11
40-4812238585 Wear part kit conveyor plates, Hardox 400 12
40-4812035553 Wear part kit reversing roller 13
40-4812029178 Wear part kit conveyor chain, single 14
40-4812027444 Wear part kit conveyor chain, double bars 15
40-D635060800A Chain guide 16
40-4812071664 Wear part kit conveyor drive 17
40-4812238489 Conveyor drive, cpl. 18
Drive kits
40-4812035550 Wear part kit rubber plates 19
40-4812075148 Wear part kit, track roller 20
40-4812076628 Wear part kit, idler 21
40-4812076502 Wear part kit, drive sprocket 22
Service kits
Service kit 500 h
40-4812074860 Service kit 500 h, Stage V 23
Service kit 1000 h
40-4812074861 Service kit 1000 h, Stage V 24
General kits
40-4812077016 Fuse and relay kit 25
40-4812064474 Plug kits 26
Mechanical, Stage V
Main frame
40-4812238421 Main frame 27
Side arm guiding
40-4812028721 Side arm guiding 28
Splash guard
40-4812238374 Splash guard 29
Steering guide
40-4812036083 Steering guide 30
Extension
40-4812232118 Extension 31
40-4812217038 Levelling arm, elect. locked
40-4812217038 Levelling arm, elect. locked 32
Levelling arm, l.h.
40-4812217282 Levelling arm, l.h. 33
Side arm guiding
40-4812232214 Side arm guiding 35
Adjusting screw
40-4812061689 Adjusting screw 36
Levelling arm, r.h.
40-4812217283 Levelling arm, r.h. 37
Side arm guiding
40-4812232214 Side arm guiding See page 35
Adjusting screw
40-4812061689 Adjusting screw See page 36
Locking, electric
40-4812217039 Locking, electric 41
Push roller
40-4812044911B Push roller, hydraulic crosshead 42
Push roller
40-4812063758 Push roller 43
Pillow block
40-4812046568 Pillow block 44
40-4812201978 Hopper with front flap
40-4812201978 Hopper with front flap 45
Hopper, l.h.
40-4812226054 Hopper, l.h. 46

TOTAL PAGES - 749

FILE FORMAT: PDF
LANGUAGE: ENGLISH
EXCEPTIONAL SUPPORT 24X7, SECURE, EASY ORDERING
COMPATIBLE: ALL VERSIONS OF WINDOWS, ANDROID & MAC
DOWNLOAD: YOU WILL RECEIVE LINK ON YOUR EMAIL AFTER PURCHASE.
