COMPLETE PDF PARTS CATALOG MANUAL FOR AMMANN AFT 700-3 SN KM3010170, AFT700-3 SN STV31358 | PUBLICATION NUMBER - 10002150LM3010165 (PDF DOWNLOAD)

1. Discover the comprehensive AMMANN AFT 700-3 Parts Catalogue Manual, designed specifically for the AFT700-3 SN KM3010170 and AFT700-3 SN STV31358 models. This PDF file serves as an essential resource for maintenance and repair, ensuring you have all the necessary information at your fingertips.

2. With detailed diagrams and part specifications, this manual simplifies the process of identifying and ordering replacement parts. Whether you're a seasoned technician or a DIY enthusiast, the user-friendly layout makes it easy to navigate and find exactly what you need to keep your equipment running smoothly.

3. Invest in the AMMANN AFT 700-3 Parts Catalogue Manual today and enhance your operational efficiency. Having this manual on hand not only saves you time but also helps prevent costly downtime, ensuring your machinery remains in peak condition for all your projects.

PUBLICATION NUMBER - 10002150LM3010165

MODEL COVERED :
AMMANN AFT 700-3 SN KM3010170, AFT700-3 SN STV31358

CONTENT INCLUDED :
Service, repair and wear part kits, Stage IIIa / Tier3
Wear part and Inspection kits TIER 3 1
Auger kits
40-4812027478 Wear part kit auger wings Ø380mm 3 40-4812075191 Renewal kit I, auger drive – Valid from 0G001393, ff. 4 40-4812075192 Renewal kit II, auger drive 5 40-4812027733 Wear part kit auger wing Ø430mm 6
Hopper / pushroller kits
40-4812018438 Wear part kit hopper rubber, front hopper flap 7 40-4812018439 Wear part kit hopper rubber, standard 8 40-4812075204 Renewal kt, push roller 9
Conveyor kit
40-4812238491 Wear part kit conveyor guide plates 10 40-4812238624 Wear part kit conveyor guide plates, Hardox 400 11 40-4812238584 Wear part kit conveyor plates 12 40-4812238585 Wear part kit conveyor plates, Hardox 400 13 40-4812035553 Wear part kit reversing roller 14 40-4812029178 Wear part kit conveyor chain, single 15 40-4812027444 Wear part kit conveyor chain, double bars 16 40-D635060800A Chain guide 17 40-4812071664 Wear part kit conveyor drive 18 40-4812238489 Conveyor drive, cpl. 19
Drive kits
40-4812035550 Wear part kit rubber plates 20 40-4812075148 Wear part kit, track roller 21 40-4812076628 Wear part kit, idler 22 40-4812076502 Wear part kit, drive sprocket 23
Service kits Service kit 500 h
40-4812024673 Service kit 500 h TIER 3 24
Service kit 1000 h
40-4812071041 Filter kit 1000h 25 40-4812071042 Service kit 1000h TIER 3 26
General kits
40-4812077016 Fuse and relay kit 27 40-4812064474 Plug kits 28
Mechanical, Stage IIIa / Tier3 Main frame
40-4812238421 Main frame 29
Side arm guiding
40-4812028721 Side arm guiding 30
Splash guard
40-4812238374 Splash guard 31
Steering guide
40-4812036083 Steering guide 32
Extension
40-4812232118 Extension 33
40-4812217038 Levelling arm, elect. locked
40-4812217038 Levelling arm, elect. locked 34
Levelling arm, l.h.
40-4812217282 Levelling arm, l.h. 35
Side arm guiding
40-4812232214 Side arm guiding 37
Adjusting screw
40-4812061689 Adjusting screw 38
Levelling arm, r.h.
40-4812217283 Levelling arm, r.h. 39
Side arm guiding
40-4812232214 Side arm guiding See page 37
Adjusting screw
40-4812061689 Adjusting screw See page 38
Locking, electric
40-4812217039 Locking, electric 43
Push roller
40-4812044911B Push roller, hydraulic crosshead 44
Push roller
40-4812063758 Push roller 45
Pillow block
40-4812046568 Pillow block 46
40-4812229083 Hopper with dump plate
40-4812229083 Hopper with dump plate 47
